Swan WRL22+WRL22S Line array speaker
$ -
Postage : $0.00
Pro Audio Line array WR Remote waterproof line array speaker
|
Product Introduction |
||
|
WR series is a new waterproof shower array external crossover speaker system introduced by HiVi Company. It is designed according to IPX6 international waterproof grade standard, and can meet professional sound reinforcement requirements in unexpected rainy weather and various harsh environments with high water density. WR series corrects the wave front to make it close to the plane wave transmission, thus solving the problem of long-distance transmission. Through the special hanging system, many speakers can be quickly connected to form a good vertical coverage line sound source, which has good directivity, high continuous sound pressure level, large dynamic and good transient. With its WR ultra-low frequency speakers, the ideal external frequency division combination configuration can achieve good sound reinforcement effect. This system is especially suitable for all kinds of indoor and outdoor gymnasiums, great halls, auditoriums, theatres, performance halls, multi-functional conference rooms and other sound reinforcement requirements; It is equipped with special hangers, bolts, all kinds of connectors and automatic positioning devices of the patented sound reinforcement pointing area.
|
||
|
Parameters |
||
|
Model |
WRL22 |
WRL22S |
|
Type |
External 3-way system |
Subwoofer |
| Frequency range |
LF：60HZ-3KHz MF：60HZ-3KHz HF：1KHz-22KHz |
30Hz-250Hz |
|
Rated power |
LF：350W MF：350W HF：150W |
800W |
|
Sensitivity |
LF：100dB MF：100dB HF：112dB |
100dB |
|
Max SPL(Peak) |
LF：131dB MF：131dB HF：140dB |
137dB |
|
Rated impedance |
LF：16Ω MF：16Ω HF：16Ω |
8Ω |
|
Speaker driver configuration |
LF：1*10”(65mm Voice coil) neodymium magnet MF :1*10”(65mm Voice coil) neodymium magnet HF :1*2.6”(65mm Voice coil) neodymium magnet |
1*18”(100mm Voice coil) neodymium magnet |
|
Input connection |
LF（1+，2-） MF（3+，4-） HF（5+，6-） |
（1+，2-） |
|
Directive system |
Laser pointing input 3+, 4- (optional) |
/ |
|
Hanging system |
Special array hanging system |
Special array hanging system |
|
Coverage angle（H×V） |
90°×10° |
/ |
|
Front protection |
Black hardened steel mesh (waterproof mesh) |
Black hardened steel mesh (waterproof mesh) |
|
Cabinet material |
Birch plywood |
Birch plywood |
|
Finish |
Environment-friendly black polyurea waterproof paint |
Environment-friendly black polyurea waterproof paint |
|
Install |
Hanging and stacking |
Hanging and stacking |
|
Size（mm）（W×H×D） |
860×303×470 |
860×555×730 |
|
N.W.(±10%) |
35KG |
68KG |
|
Instructions for laser pointing and positioning in sound reinforcement area |
||
1. First, make sure that the power amplifier is properly connected to the port of 8-core waterproof speaker base (3+, 4-). When a low-voltage 15KHz sine wave signal is input, a slight high-frequency sound of the woofer will be heard. Then, continue to slowly increase the input signal voltage until the laser light outlet on the front of the speaker emits a stable beam, and the projection position of the beam is the sound reinforcement pointing area of the speaker.
Note: When using this function, please mute the ports of (1+, 2-) and (5+, 6-) to prevent the horn from burning out.
2. Schematic diagram of laser beam positioning, as shown in the figure.
Note: This pointing system is optional. Please make sure the speaker has this function before using it.
|
||
|
Product Size |
||
|
|
||
|
Install |
||
|
|
||
