Swan T3 series line array speakers
$ -
Postage : $0.00
Pro Audio Line array T3 series Line array speaker
|
Coverage angle（H×V） |
120°×30° |
120°×30° |
120°×30° |
Full directive |
Full directive |
|
Woofer |
8×3”（25mm voice coil） |
6×3”（25mm voice coil） |
4×3”（25mm voice coil） |
15”（75mm voice coil） |
1×15”（75mm voice coil） |
|
Tweeter |
2×3”cone |
2×3”cone |
/ |
/ |
/ |
|
Size（W×H×D） |
112.5×992×130mm |
136×948.2×220mm |
136×497.5×148.9mm |
465×648×633.5mm |
465×648×633.5mm |
|
N.W.±10%) |
8KG |
10KG |
4.6KG |
40KG |
38.5KG |
|
Model |
T3S-A |
|
With bluetooth function, with DSP; flexible combination of multiple frequency division modes, high and low-pass frequency division points can reach 20Hz ~ 20KHz; provide USB interface to connect to computer; directly use the function keys and pulleys on the panel to set functions or It is connected to a computer and controlled by PC control software, which is very convenient, intuitive and concise; four user programs can be stored in a single machine; both input and output have 8 independent parametric equalization, and the adjustment gain range can reach ±15dB; Time and phase control and mute settings, the delay can be up to 5ms, and the delay unit can be selected from three types: milliseconds (ms), meters (m), and feet (ft). |
|
|
F1 power（1KHz/8Ω）（drive T3A） |
280W±10% |
|
F28Ωpower（1KHz/8Ω）（drive T3B） |
260W±10% |
|
SUB power（1KHz/8Ω）（drive T3S） |
1000W±10% |
| Continuous power rating | 1000W |
| Impedance | 4Ω |
| Sensitivity |
96dB-SPL,1W,1m（pink noise） |
|
Maximum sound output |
120dB-SPL, 1m（pink noise） |
|
Total Harmonic Distortion: Bass, f=60Hz, Treble, f=1kHz, normal operating conditions |
≤0.08% |
|
Minimum source EMF: DSP volume 0dB F1 channel |
1.0V±10% |
|
Minimum source EMF: DSP volume 0dB F2 channel |
1.0V±10% |
|
Minimum source EMF: DSP volume 0dB SUB channel |
1.0V±10% |
|
BT function, connection distance |
≥10 meters |
|
【Computer operating software】 |
|
|
Product size |
|
