It is suitable for the low frequency unit in the Hi-Fi two-way phase inverted speaker system and the mid-range unit in the three-way system.
|
Swan E8N Parameters
|
|||
| Parameters | Mark | Value | Unit |
| Basic application parameters | |||
| Rated impedance | Z | 8 | Ω |
| Resonant frequency | Fs | 35 | Hz |
| Rated power | Pnom | 80 | W |
| Maximum power | Pmax | 160 | W |
| Sensitivity (2.83V/1m) | E | 89 | dB |
| Weight | W | 2.71 | kg |
| Voice coil | |||
| Voice coil diameter | ? | 35 | mm |
| DC Resistance | Re | 7.2 | Ω |
| Voice coil width | H | 17.8 | mm |
| Voice coil material | High temperature SV wire | ||
| Voice coil bobbin | AL | ||
| Magnetic circuit | |||
| Magnetic circuit type | Dual magnetic antimagnetic | ||
| Magnet material | High performance ferrite | ||
| Force coefficient (BL value) | BL | 10.4 | N/A |
| Magnetic gap height | He | 8 | mm |
| Maximum Linear Displacement | Xmax | 4.9 | mm |
| Small/Thiele Parameters | |||
| Consistency | Cms | 809 | uM/N |
| Mechanical Q | Qms | 2.46 | - |
| Electric Q value | Qes | 0.37 | - |
| Total Q | Qts | 0.33 | - |
| Vibration mass | Mms | 24.28 | g |
| Equivalent volume | Vas | 52.5 | L |
| Recommended cabinet parameters | |||
| Cabinet type | Phase inverted | ||
| Recommended net volume of box | Vb | 28.5 | L |
| Inverter tuning frequency | Fb | 33 | Hz |
| Cabinet at -3dB frequency in free field | F3 | 36 | Hz |
|
Swan E8N Parameters
|
|||
| Parameters | Mark | Value | Unit |
| Basic application parameters | |||
| Rated impedance | Z | 8 | Ω |
| Resonant frequency | Fs | 35 | Hz |
| rated power | Pnom | 80 | W |
| Maximum power | Pmax | 160 | W |
| Sensitivity (2.83V/1m) | E | 89 | dB |
| Weight | W | 2.71 | kg |
| Voice coil | |||
| Voice coil diameter | ? | 35 | mm |
| DC Resistance | Re | 7.2 | Ω |
| Voice coil width | H | 17.8 | mm |
| Voice coil material | High temperature SV wire | ||
| Voice coil bobbin | AL | ||
| Magnetic circuit | |||
| Magnetic circuit type | Dual magnetic antimagnetic | ||
| Magnet material | High performance ferrite | ||
| Force coefficient (BL value) | BL | 10.4 | N/A |
| Magnetic gap height | He | 8 | mm |
| Maximum Linear Displacement | Xmax | 4.9 | mm |
| Small/Thiele Parameters | |||
| Consistency | Cms | 809 | uM/N |
| Mechanical Q | Qms | 2.46 | - |
| Electric Q value | Qes | 0.37 | - |
| Total Q | Qts | 0.33 | - |
| Vibration mass | Mms | 24.28 | g |
| Equivalent volume | Vas | 52.5 | L |
| Recommended cabinet parameters | |||
| Cabinet type | Phase inverted | ||
| Recommended net volume of box | Vb | 28.5 | L |
| Inverter tuning frequency | Fb | 33 | Hz |
| Cabinet at -3dB frequency in free field | F3 | 36 | Hz |
