Product Description
The WR series is a new waterproof shower line array external frequency crossover speaker system launched by HiVi. It is designed in accordance with the IPX6 international waterproof level standard and can meet the needs of professional sound reinforcement in unexpected rainy weather and various harsh environments with high water density. need. The WR series corrects the wave front to make it close to the plane wave transmission, so as to solve the problem of long-distance transmission. Through the special hanging system, multiple speakers can be quickly matched and connected to form a good vertical coverage surface line sound source. It has good directivity, high continuous sound pressure level, high dynamics and good transient state. It can achieve good sound reinforcement effect with its WR subwoofer and ideal external frequency division combination configuration. This system is especially suitable for various indoor and outdoor gymnasiums, assembly halls, auditoriums, theaters, performance halls, multi-functional conference rooms and other sound reinforcement needs; and is equipped with special hangers, plugs, various connectors and patented sound reinforcement pointing areas automatic positioning device, etc.
Parameters
Model	WRL33	WRL33+	WRS3	WRS3+
Type	External two-way speakers	External two-way speakers	Three 18" subwoofers	Three 18" subwoofers
Frequency range	LF：50HZ-1KHz MF+HF：500Hz-18KHz	LF:50Hz-1KHz MF+HF:500Hz-18KHz	Front：30Hz-250Hz Back：30Hz-250Hz	Front：30Hz-250Hz Back：30Hz-250Hz
Rated power	LF：800W MF+HF：600W	LF:900W MF+HF:600W	Front：1200W Back：600W	Front：1600W Back：800W
Sensitivity	LF：102dB MF+HF：115dB	LF:103dB MF+HF:116dB	Front：102dB Back：97dB	Front：103dB Back：98dB
Max SPL (Peak)	LF：137dB MF+HF：148dB	LF:138dB MF+HF:149dB	Front：139dB Back：131dB	Front：141dB Back：133dB
Rated impedance	LF：16Ω MF+HF：8Ω	LF:8Ω MF+HF:8Ω	Front：4Ω Back：8Ω	Front：4Ω Back：8Ω
Speaker configuration	LF：212”(75mm voice coil)ferromagnetic MF :110”(75mm voice coil)ferromagnetic HF :2*3”(75mm voice coil)Neodymium magnet	LF:212"(75mm voice coil)Neodymium MF:110"(75mm voice coil)ferromagnetic HF:2*3"(75mm voice coil)Neodymium	3*18”(100mm voice coil)ferromagnetic	3*18”(100mm voice coil)Neodymium
Input connection	LF（1+，2-） MF+HF：（3+，4-）	LF(1+,2-) MF+HF(3+,4-)	Front（1+，2-） Back（3+，4-）	Front（1+，2-） Back（3+，4-）
Directive system	laser pointing input（1+，2-）	laser pointing input1+,2-	/	/
Hanging system	Dedicated array suspension system	Dedicated array suspension system	/	/
Coverage angle(HXV)	90°×7°	90°X7°	/	/
Front protection	Black hardened steel mesh (waterproof mesh)	Black hardened steel mesh (waterproof mesh)	Black hardened steel mesh (waterproof mesh)	Black hardened steel mesh (waterproof mesh)
Cabinet material	birch plywood	birch plywood	birch plywood	birch plywood
Cabinet finish	Environmentally friendly wear-resistant black polyurea waterproof paint	Environmentally friendly wear-resistant black polyurea waterproof paint	Environmentally friendly wear-resistant black polyurea waterproof paint	Environmentally friendly wear-resistant black polyurea waterproof paint
Install	hanging, stacking	hanging, stacking
Size(mm) (WXHXD)	1130×366×583	1130X366X583	1136×545×994	1136×545×994
N.W.(±10%)	74KG	68Kg	107KG	95KG
Instructions for laser pointing and positioning in the sound reinforcement area
1. First make sure that the power amplifier and the 8-pin waterproof speaker stand (1+, 2-) port are connected correctly, input a low voltage 15KHz sine wave signal, you will hear the slight high frequency sound of the woofer, and then continue to slowly increase the input signal voltage , until the laser light outlet on the front of the speaker emits a stable beam, and the projection position of the beam is the sound reinforcement pointing area of the speaker. Note: When using this function, please mute the ports (3+, 4-) to prevent the speakers from being burned. 2. Schematic diagram of laser beam positioning, as shown in the figure. Note: This pointing system is an optional accessory, please make sure that the speaker has this function before using it.
